Operational Specifications
3.1.4 External Power Supply Connectors (J4)
Rev.1.0 July 21, 2006 3-6
REJ10J0952-0100
3
3.1.4 External Power Supply Connectors (J4)
The M3A-HS25 includes external power supply connectors for the SH7125.
Figure3.1.5 shows a pin assignment of power supply connector.
Board
edge
Top view of the
component side
J4
VCC
1 2
Figure3.1.5 Pin Assignment of Power Supply Connector (J4)
Table 3.1.4 lists pin assignments of power supply connector for the SH7125.
Table 3.1.4 Pin Assignment of Power Supply Connector (J4)
Pin Signal Name Pin Signal Name
1 +5V 2 GND
