Page 26
Operational Specifications
3.1 M3A-HS25 Connectors Outline
3
3.1 M3A-HS25 Connectors Outline
Figure3.1.1 shows the M3A-HS25 connector assignments.
J7
Extension
connector
(Not mounted)
J2
Serial Port
Connector
J1
H-UDI
Connector
J3
Power Supply
connector
J4
External Power
Supply Connector
(Not mounted)
< Top view of the solder side >
J5
Extension Connector
(Not mounted)
J6
Extension Connector
(Not mounted)
Figure3.1.1 M3A-HS25 Connector Assignments
Rev.1.0 July 21, 2006
3-2
REJ10J0952-0100
