5
replace commonsense and navigational judgement. Always
maintain a permanent watch so you can respond to situations as
they develop.
EMC Installation Guidelines
Please refer to the SmartPilot Commissioning Guide for applicable EMC
guidelines
Product disposal
When you want to dispose of this product (for example, at the end of its
working life), please do so in accordance with local regulations.
1.4S3G Course Computer
Please refer to the SmartPilot Commissioning Guide for detailed installation
instructions for the IPS S3G and fluxgate compass.
1.5 Control Head
Please refer to the Control Head installation sheet for detailed installation
instructions.
1.6 Data Processing Unit (DPU)
D5536-1
5.9 in (150 mm)
1.53 in
(39 mm)
5.12 in (130 mm)
87054_3.book Page 5 Tuesday, July 18, 2006 8:49 AM
