16 volvo penta ips autopilot system – Raymarine VolvoPenta IPS Autopilot System DPU User Manual
Page 16
16
Volvo Penta IPS Autopilot System
Computer
power supply
(via breaker/fuse)
SeaT
alk
2
Connector Block
V
o
lvo Penta IPS
Autopilot
System Connections
(Single power supply)
Ye
llow grounding cable
ST6001
Control Head
RS125
GPS
RF ground
Compass
Junction Box
IPS Data Processing Unit
D8055-3
S3G Course Computer
12345
to V
olvo
Penta
Autopilot
Interface Unit
CAUTION
DO NOT CONNECT
TO NMEA2000 BUS
87054_3.book Page 16 Tuesday, July 18, 2006 8:49 AM
