Page 10
10
Volvo Penta IPS Autopilot System
1.9 Cable preparation
In an IPS system, cables not already fitted with molded connectors must be
correctly prepared for connection.
The DPU uses color coded, spring retention connectors. To make a secure
connection to a spring retention connector, prepare the cable for connection, then
use the method illustrated below to connect each wire.
1.10 Connections to DPU
The diagram below illustrates the connections that are required to and from the
DPU.
Ferrites
Ensure that all cables connected to the DPU have a clip on ferrite fitted.
50 mm
9 mm
D5905-1
9 mm
D5907-1
87054_3.book Page 10 Tuesday, July 18, 2006 8:49 AM
