56 C-Series Display Reference Manual
4.9 Navigating to a specific point
You can use your chart to navigate to a specific point marked by the cursor (temporary
waypoint) or to a waypoint. If required you can display the largest chart scale possible
that will display both your boat and the target waypoint. When you navigate to a
waypoint or to the cursor position, the data is sent on NMEA 0183 and SeaTalk and can
be used by an autopilot, if connected. On arrival at the specified point a message is
displayed and an alarm sounds.
When you are steering manually, you can also use the chart to determine the bearing
or direction to steer.
Note: If you are currently navigating a route or going to the cursor /waypoint, you
must press STOP GOTO, before the system can commence a new GOTO request.
To go to the cursor position:
Note: This target waypoint is also identified on the radar
D6608-3
GOTO CURSOR
STOP GOTO RESTART XTE
4nm North-Up (Relative Motion) Local
Boat's heading changes
to follow course to
temporary waypoint Press to stop GOTO
and remove
temporary waypoint Dashed line
marking original
course of GOTO Temporary waypoint
(within white box)
placed at cursor Temporary
waypoint
name
GOTO...
D6493-2
GOTO CURSOR
Position cursor at
desired destination Temporary waypoint
placed at the cursor.
