152
C-Series Display Reference Manual
7.3 Selecting the data for display
You can either select a panel of pre-configured data or customize the application to
display the data of your choice.
Note:
Panel selection is a local setting and will therefore only affect the individual dis-
play on which you are working.
Pre-configured data panels
The pre-configured data panels include data associated with Navigation, Waypoint,
Route, Fishing or Sailing:
Vessel position
Active waypoint
TTG
VMG - Waypoint
Depth
Cog Sog
Heading
Speed
Set/Drift
XTE
Trip
Local time
Sea temperature
Ground wind
App wind
True wind
VMG wind
Panel Type
Navigation
Waypoint
Route
Fishing
Sailing
D8950_1
Data content
81221_4.book Page 152 Tuesday, February 28, 2006 5:24 PM
