Vertical and horizontal lens shift, 17. vertical and horizontal lens shift adjustments, Pre l iminar y – Runco Video Xtreme VX-6000d User Manual
Page 53
Runco VX-6000d Owner’s Operating Manual
41
PRE
L
IMINAR
Y
Vertical and Horizontal
Lens Shift
To change the projected image position, use a 3/16” hex driver to shift the lens in the
desired direction; see Figure 3-17. The vertical lens shift control is at the top of the
projector; the horizontal lens shift control is on the side of the projector nearest the Runco
logo. (The tool will automatically center on top of the adjustment nut when inserted into
the access hole.)
Figure 3-17. Vertical and Horizontal Lens Shift Adjustments
Vertical Lens Shift
Horizontal Lens Shift
