Before using this unit, carefully read the sections entitled:

“USING THE UNIT SAFELY” (p. 13–p. 14)

and

“IMPORTANT NOTES” (p. 15)

.

These sections provide important information concerning the proper operation of the unit.
Additionally, in order to feel assured that you have gained a good grasp of every feature
provided by your new unit, Owner’s manual should be read in its entirety.

The manual should be saved and kept on hand as a convenient reference.

Copyright © 2006 ROLAND CORPORATION

All rights reserved. No part of this publication may be reproduced in any form without the written
permission of ROLAND CORPORATION.

Owner’s Manual

04455178 1MP

2

Attaching the Ferrite Core

You must attach the ferrite core before using the M-10MX.

If you connect the M-10MX’s coaxial jack to your digital device, you must attach the included ferrite
core.

This is for the purpose of preventing electromagnetic noise; do not remove it.

fig.ferraite-1

1.

Attach the ferrite core to the coaxial cable.

* You must attach it near the M-10MX.

fig.ferraite-2

2.

Wrap the coaxial cable around the ferrite
core; one turn is enough.

fig.ferraite-3

3.

Press the halves together until they click
shut.

* Be careful not to pinch your fingers when attaching the ferrite core.

* Do not damage the cable by pinching it excessively with the ferrite core.

Ferrite Core

For the USA

FEDERAL COMMUNICATIONS COMMISSION

RADIO FREQUENCY INTERFERENCE STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.

Unauthorized changes or modification to this system can void the users authority to operate this equipment.
This equipment requires shielded interface cables in order to meet FCC class B Limit.
