Loading Paper and Other Media
45
4
B
Load the paper completely into
the tray.
Important
❒ Align the paper to the each side
completely.
❒ Do not stack paper over the lim-
it mark.
❒ Confirm that the end fence locks
completely after loading the
right side paper.
❒ If you want to change the paper
size, contact your sales or ser-
vice representative.
Note
❒ Shuffle the paper before setting
in the tray.
❒ Load the paper face up onto the
tray.
C
Slide the tray into the printer un-
til it stops.
Loading Paper in Bypass Tray
Type 270
Note
❒ Paper sizes supported by the by-
pass tray are approximately 90 -
297mm (Metric version) or 3.54 -
11.69" (Inch version) in width, and
approximately 148 - 432mm (Met-
ric version) or 5.83 - 17.00" (Inch
version) in length. Set the custom
size to specify with the printer
driver or the operation panel. For
more information on using the op-
eration panel, see P.48 “Specifying
the Custom Paper Size for the Bypass
Tray”.
❒ If you load thick paper, OHP trans-
parencies or envelopes, set the
printer to the “Thick paper” mode
using the printer driver.
Limitation
❒ The function with using the bypass
tray is not available.
• Duplex print
• Sort, Shift Sort
• Staple
• Limitless paper feed
• Proof Print
A
Open the bypass tray.
ZAEY201E
ZAEY040E
