– 31 –
YOUR WEEKLY TIMER PROGRAM
Points to consider before writing your program:
When do I want the heater to operate, and what temperature do I want?
When do I not want the heater to operate?
Will I use the same settings for everyday day of the week, or do I need a separate program for the
weekdays, and the weekend? Do I need a separate setting for each day of the week?
Points to remember when writing your program:
The four periods are set within a 24 hour time span.
The start of a new period marks the end of the previous one, so each period only requires a START time.
Period 4 ends with the start of period 1 on the next day(see page 26 for a reminder).
Each period must be set to a later time than the one before it.
If you want to heat during the period, select a temperature: H(high), 80 60, L(low).
If you do not want to heat during this period, select the OFF setting.
Write your own program:
Use the tables below to write your own weekly timer program, then turn to page 28 to program the timers.
Start Time Temperature or OFF
1
2
3
4
Start Time Temperature or OFF
1
2
3
4
6:00 am
8:30 am
5:00 pm
11:30 pm
72 F
60 F
74 F
60 F
7:00 am
12:00 pm
5:00 pm
11:30 pm 72 F
70 F
74 F
60 F
Start Time Temp or OFF
1
2
3
4
WEEK DAY
Temp or OFF
1
2
3
4
WEEK END
Start Time
FACTORY PRE-SET PROGRAM
The heater comes shipped with a factory set
program(opposite).
If the heater is not set with a new program it will run
according to this program when you operate the
timers(“Auto” mode-see page 32).
If the Weekly Timer program settings are erased
(see page 24), the heater will revert to this program.
