PROGRAMING THE TIMERS : EXAMPLE cont...
Press the “Select” button again. Now the
period
2
indicator will flash and the time
and temperature display will be shown.
8
Press the “Select” button again. The
period
2
indicator will become stable,
the temperature display will go out and
the clock indicator will flash.
9
Press the “
” button until the display
shows “
am
8:00”(as in the example on
page 28 for period
2
).
10
Press the “Select” button again. The clock
indicator will become stable, the pre-set
temperature will flash and “Select Program
Temp” will be shown.
11
Press the “
” button until the
temperature shows “- -” and the “OFF”
indicator is displayed.
12
Press the “Select” button again. The
period 1 indicator will flash and “Sa Su”
will be displayed.
14
Once all timers are programed, Press the
“Timers” button once to save all timer
settings. The display will return to the
current time and the “Set Program Timer”
indicator will go out.
16
Set periods
3
and
4
following/repeating steps to , and then go to step .
13
You can now program a Weekend schedule by repeating steps to , and then go to step .
15
Press the “
” button to set the pre-set
temperature to 76 F(remember, we are
using the example schedule on page 28).
7
To review all of the programed settings turn to page 30- “WEEKLY TIMER REVIEW FUNCTION”.
For a description of how to operate the heater with these programed settings, turn to page 32- “OPERATING
THE TIMERS”.
