8
4. Insert the supplied AC adapter’s
barrel plug into the DC 9V jack on
the back of the base.
5. Route the adapter’s cord through
the strain relief slot on the back of
the base.
6. Insert the tabs on the narrow end of
the bracket into the inner pair of
slots near the bottom of the base
and snap the tabs at the wide end of
the bracket into place.
Strain
Relief
Slot
7. Plug the adapter into a standard AC
outlet. The TAD-733 beeps and 00
appears.
8. Raise the base’s antenna to a verti-
cal position.
On a Wall Plate
1. Follow Steps 1–4 under “On a Desk
Top” on Page 7.
2. Route the modular cord through the
left groove on the bottom of the
base and the adapter cord through
the groove below the strain relief
slot.
3. Route the end of the modular cord
through the hole in the bracket, and
insert the tabs on the narrow end of
the bracket into the inner pair of
slots near the top of the base.
Strain
Relief
Slot
