RedMax GZ7000 - Manual (Page 147)

147
Key# PART NUMBER DESCRIPTION QTY/UNIT NOTE
0 544 19 98-01 CARBURETTOR 1
1 503 48 05-01 SCREW 4
2 537 38 37-01 COVER 1
3 537 38 35-01 DIAPHRAGM 1 Part of 55
4 537 38 36-01 GASKET 1 Part of 55
5 503 48 18-01 SCREW 1
6 537 26 68-01 VALVE 1
7 503 48 00-01 PIN RETAINING SCREW 1
8 503 47 97-01 VALVE 1
9 503 48 01-01 SCREW 1
10 503 66 59-01 LEVER 1
11 544 23 78-01 SHAFT 1
12 537 17 70-01 VALVE 1
13 503 48 18-01 SCREW 1
14 544 19 98-01 CARBURETTOR 1
15 537 38 51-01 SCREW 2
16 537 38 50-01 CLIP 1
17 537 38 53-01 GASKET 1 Part of 55
18 537 38 55-01 SPRING 1
19 544 23 79-01 ROD 1
20 537 38 34-01 SPRING 1
21 503 53 56-01 PLUG WELCH 1
22 544 23 77-01 NOZZLE ASSY 1
23 537 01 25-01 BALL 1
24 537 01 26-01 SPRING 1
25 537 38 42-01 SHAFT ASSY 1
26 544 23 80-01 LEVER 1
27 537 38 44-01 SPRING 1
28 503 47 90-01 SCREW 1
29 537 21 37-01 LEVER 1
30 537 38 41-01 LEVER 1
31 537 38 52-01 CLIP 1
32 544 19 98-01 CARBURETTOR 1
33 503 53 57-01 STRAINER 1
34 537 38 29-01 SPRING 1
35 537 27 42-01 BOOT 1
36 503 90 34-01 RETAINER 1
37 503 97 40-01 WASHER 2
38 537 38 38-01 SCREW 1
39 537 38 47-01 LIMITER CAP 1
40 537 38 46-01 LIMITER CAP 1
41 537 38 39-01 SCREW 1
42 537 38 45-01 LEVER 1
43 503 47 90-01 SCREW 1
44 537 38 28-01 SHAFT ASSY 1
45 537 38 30-01 VALVE 1
46 503 48 18-01 SCREW 1
47 537 38 31-01 DIAPHRAGM PUMP 1 Part of 55
48 537 40 33-01 DIAPHRAGM 1 Part of 55
49 537 02 01-01 GASKET PUMP 1 Part of 55
50 537 38 32-01 COVER 1
51 503 47 96-01 SCREW 1
52 503 48 11-01 PIECE 1
53 537 38 33-01 SCREW 1
55 537 38 56-01 SET OF GASKETS 1
