139
Key# PART NUMBER DESCRIPTION QTY/UNIT NOTE
1 505 25 98-01 HAND GUARD 1
2 537 20 90-01 SCREW 2
3 537 20 28-01 BUSHING 2
4 537 21 07-01 SPRING GUIDE 1
5 503 43 65-01 POSITION SPRING 1
6 537 20 31-01 LOCK 1
7 501 87 53-04 KNEE JOINT 1
8 503 21 28-10 SCREW CCRPANT 1
9 503 70 99-01 BRAKE SPRING 1
10 503 79 27-01 SUPPORT 1
11 503 75 22-02 BRAKE BAND ASSY 1
12 503 21 70-72 SCREW CCRPANT 4
13 537 20 32-01 CAP 1
14 537 20 36-01 GUIDE BUSHING 1
15 537 20 35-03 CARBURETTOR AREA BAS 1
16 503 20 07-12 SCREW IHSCEM 4
17 503 86 93-01 CARBURETTOR MOUNTING 2
18 537 20 38-01 GROMMET 1
19 537 20 53-01 SEALING 1
20 537 20 52-02 CHOKE CONTROL 1
21 537 20 87-01 GROUND CABLE 1
22 503 86 97-02 SHORT CIRCUIT SPRING 1
23 537 20 51-02 STOP CONTROL 1
