RedMax GZ7000 - Manual (Page 127)

127
Key# PART NUMBER DESCRIPTION QTY/UNIT NOTE
1 505 12 49-02 STARTER ASSY 1
2 505 30 51-25 㹺STARTER CORD 1
3 544 37 65-01 㹺STARTER HANDLE 1
4 505 09 50-01 㹺STARTER HOUSING 1
5 537 28 32-01 㹺㹺REINFORCEMENT SLEEVE 1
6 544 08 03-01 㹺SCREW 4
7 537 28 34-01 㹺SPRING CASSETTE ASSY 1
8 503 21 28-13 㹺SCREW CCRPANT 2
9 537 20 24-01 㹺STARTER PULLEY ASSY 1
10 503 20 52-16 㹺SCREW IHSCFMT 1
11 537 20 26-01 㹺AIR CONDUCTOR 1
12 510 10 04-02 LABEL 1
C
Key# PART NUMBER DESCRIPTION QTY/UNIT NOTE
1 537 20 96-01 FLYWHEEL ASSY 2
2 503 23 00-42 2
3 501 67 35-01 2
4 501 67 32-01 2
5 501 81 99-01 2
6 503 22 04-01 NUT 1
7 510 11 57-01 IGNITION MODULE 1
8 503 20 02-20 SCREW IHSCFM 1
9 537 20 86-01 SHORT CIRCUIT CABLE 1
10 501 48 54-02 SPARK PLUG CAP 1
D
