125
Key# PART NUMBER DESCRIPTION QTY/UNIT NOTE
1 505 12 98-03 CLUTCH COVER ASSY 1
2 501 51 72-01 㹺CHAIN GUIDE 1
3 503 76 29-02 㹺CHIP GUARD 1
4 503 89 70-01 㹺SLEEVE 1
5 503 21 28-10 㹺SCREW CCRPANT 1
6 537 04 41-02 CHAIN TENSIONER 1
7 537 01 68-01 㹺COVER 1 Kit
8 537 07 94-02 㹺WORM WHEEL 1
9 503 23 00-63 㹺WASHER STEEL 1
10 740 48 07-02 㹺O-RING 1
11 503 23 00-66 㹺WASHER STEEL 1
12 537 07 95-02 㹺WORM SCREW 1
13 503 99 83-01 㹺PAWL 1
14 537 01 74-01 㹺BEARING SLEEVE 1
15 503 22 00-01 NUT FLANGE 2
16 503 21 28-10 SCREW CCRPANT 2
17 503 71 97-01 SPIKE OUTER 1
18 510 10 05-02 LABEL 1
A
Key# PART NUMBER DESCRIPTION QTY/UNIT NOTE
1 502 44 04-02 CLUTCH DRUM 1 3/8"x7T
1 502 44 04-03 CLUTCH DRUM 1 3/8"x8T
2 503 43 20-01 㹺NEEDLE HOLDER 1
3 501 59 80-02 㹺GEAR WHEEL 1 3/8"x7T
3 505 30 36-61 㹺GEAR WHEEL 1 3/8"x8T
4 503 75 24-01 WASHER 1
5 503 27 21-01 LOCK WASHER 1
6 503 74 44-05 CLUTCH ASSY 1
7 537 36 06-01 㹺CLUTCH SPRING 3
8 503 52 13-03 OIL PUMP ASSY 1
9 503 62 49-01 㹺SEALING PLUG 1
10 503 52 15-01 㹺PUMP PISTON 1
11 503 23 00-04 㹺WASHER STEEL 2
12 501 61 58-01 㹺SPRING 1
13 503 81 30-01 㹺SPRING 1
14 503 81 13-01 㹺PIN SCREW 1
15 537 20 91-01 OIL PRESSURE HOSE 1
16 537 20 78-04 PUMP PINION 1
17 503 20 53-01 SCREW IHSCM 2
18 501 89 53-01 OIL HOSE 1
19 501 54 41-02 OIL SCREEN 1
20 503 86 17-03 CLUTCH DRUM 1
21 503 43 20-01 NEEDLE HOLDER 1
B
EPA III
