Renesas H8/36912 User Manual
Page 26
12
2.5
Resulting Dimensions after Connecting User System Interface Cable
The resulting dimensions, after connecting the user system interface cable head to the user system,
are shown in figure 8.
19.7
29.2
IC socket
(NQPACK032SA
manufactured by
Tokyo Eletech Corporation)
Cable head
User system
Unit: mm
Tolerance: ±0.5 mm
Figure 8 Resulting Dimensions after Connecting User System Interface Cable
