Table 1 lists the HS36902ECH61H components. Please make sure you have all of these
components when unpacking.
Table 1 HS36902ECH61H Components
No. Component Quantity Remarks
1 Cable body 1 Coaxial cable
2 Cable head 1
3 IC socket 1 For the FP-32A package
4 Socket cover 1 For installing an FP-32A-packaged MCU
5 Screws (M2 x 10 mm) 4 For fastening cable head
6 Screws (M2 x 6 mm) 4 For installing an FP-32A-packaged MCU
7 CTS screws (M3 x 6 mm) 2 For fastening the emulator station
8 Screwdriver 1 For tightening screws
9 Documentation 1 User’s manual for HS36902ECH61H (this
manual)
10 Guide pins (
φ
1.0 mm) 2 For determining the IC socket location
