Chapter 3: Operation 3-43
When waypoints are transmitted by other equipment they are added
to the Waypoint List on the display unit. Routes transmitted on
NMEA are appended to the Route List.
3. To disable waypoint transfer, press the soft key STOP RECEIVING WAY-
POINTS.
Alternatively, press CLEAR twice to close the Waypoint List.
Note: Where multiple waypoints have the same position, the last way-
point sent is the only one included in the Waypoint List.
Sending Waypoints to Other Equipment
➤
To send the Waypoint List on NMEA:
1. Display the Waypoint List as previously described, then press the
WAYPOINT TRANSFER soft key.
2. Press the SEND WPT LIST ON NMEA soft key; the soft key changes to
STOP SENDING WAYPOINTS.
The Waypoint and Route Lists are transmitted from the display unit
to other equipment on NMEA.
3.8 Using a C-Map User Card
Waypoints/Routes can be saved to or loaded from a C-Map User Card.
By this means, you can maintain a backup of your Waypoints and Routes,
transfer them to another vessel or extend the capacity of your unit by, for
example, keeping separate User Cards for different areas.
Saving Waypoints/Routes to a User Card
CAUTION:
Saving data to your User Card will overwrite all existing Waypoint
and Route data on the card.
➤
To save to a C-MAP User Card:
1. Press MARK; the Waypoint soft keys are displayed, see Figure 3-44.
Figure 3-44: Waypoint Soft Keys
2. Insert a C-MAP User Card into the lower of the two cartridge slots.
3. Press the LOAD/SAVE USER CARD soft key; the User Card Menu is dis-
played, together with it’s associated soft keys, see Figure 3-45.
PLACE WPT
AT CURSOR PLACE WPT
AT VESSEL WAYPOINT
LIST
LOAD/SAVE
USER CARD
D5521-1
