Appendix B Pinouts
NI PXIe-1065 User Manual B-6 ni.com
Table B-10. P2 Connector Pinout for the Peripheral Slot
Pin Z A B C D E F
22 GND GA4 GA3 GA2 GA1 GA0 GND
21 GND PXI_LBR0 GND PXI_LBR1 PXI_LBR2 PXI_LBR3 GND
20 GND PXI_LBR4 PXI_LBR5 PXI_LBL0 GND PXI_LBL1 GND
19 GND PXI_LBL2 GND PXI_LBL3 PXI_LBL4 PXI_LBL5 GND
18 GND PXI_TRIG3 PXI_TRIG4 PXI_TRIG5 GND PXI_TRIG6 GND
17 GND PXI_TRIG2 GND RSV PXI_STAR PXI_CLK10 GND
16 GND PXI_TRIG1 PXI_TRIG0 RSV GND PXI_TRIG7 GND
15 GND PXI_BRSVA15 GND RSV PXI_LBL6 PXI_LBR6 GND
14 GND RSV RSV RSV GND RSV GND
13 GND RSV GND V(I/O) RSV RSV GND
12 GND RSV RSV RSV GND RSV GND
11 GND RSV GND V(I/O) RSV RSV GND
10 GND RSV RSV RSV GND RSV GND
9 GND RSV GND V(I/O) RSV RSV GND
8 GND RSV RSV RSV GND RSV GND
7 GND RSV GND V(I/O) RSV RSV GND
6 GND RSV RSV RSV GND RSV GND
5 GND RSV GND V(I/O) RSV RSV GND
4 GND V(I/O) 64EN# RSV GND RSV GND
3 GND PXI_LBR7 GND PXI_LBR8 PXI_LBR9 PXI_LBR10 GND
2 GND PXI_LBR11 PXI_LBR12 UNC PXI_LBL7 PXI_LBL8 GND
1 GND PXI_LBL9 GND PXI_LBL10 PXI_LBL11 PXI_LBL12 GND
