Appendix A Specifications
NI PXIe-1065 User Manual A-2 ni.com
DC Output
DC current capacity (I
MP
)
Note Maximum combined +3.3 V, +5 V, and +12 V power is 699 W.
Maximum total power is 701.5 W.
The maximum power dissipated in the system slot should not exceed 140 W.
Backplane pin current capacity
Load regulation
Voltage Maximum Current
+3.3 V 61 A
+5 V 56 A
+12 V 45 A
–12 V 4 A
5 V
AUX
1.5 A
Slot +5 V V (I/O) +3.3 V +12 V –12 V 5 V
AUX
System Controller Slot 9 A 0 A 9 A 11 A 0 A 1 A
System Timing Slot 0 A 0 A 3 A 2 A 0 A 1 A
Hybrid Peripheral Slot with
PXI-1 Peripheral 6 A 5 A 6 A 1 A 1 A 0 A
Hybrid Peripheral Slot with
PXI-5 Peripheral 0 A 0 A 3 A 3 A 0 A 1 A
PXI-1 Peripheral Slot 6 A 11 A 6 A 1 A 1 A 0 A
Voltage Load Regulation
+3.3 V <5%
+12 V <5%
+5 V <5%
–12 V <5%
