NTI AUDIO/HD VIDEO MATRIX SWITCH
22
Web Interface
A user may control the connections of the VEEMUX-A using a Web Interface via any web browser (see page 1 for web supported
browsers). With the VEEMUX-A connected to a LAN through an Ethernet cable, a user can access the web interface controls
inside the VEEMUX-A.
FYI: To quickly locate a VEEMUX-A on the LAN and edit the IP address settings, use the Device Discovery Tool (page
31).
To access the web interface, type the current IP address into the address bar of the web browser.
Address
To open an SSL-encrypted connection, type:
Address
You will be prompted to accept a certificate. Accept the NTI certificate.
A "Welcome Page" will appear.
Figure 8- Web interface Welcome page
Enter the Password
Click on a link to the left to be prompted for a username and password. To change the password, see page 30.
User Name = Administrator (upper case letter for "A" only)
Password = admin (lower case letters only)
Note: The browser must be configured
to accept cookies in order for the user to
successfully make use of the web
interface.
Figure 9- Web interface Login Prompt
As described on the following pages, each link will enable different areas of control for the VEEMUX-A.
http://192.168.1.30
https://192.168.1.30
