Volume Control
The volume level can be adjusted on each output port.
• To increment <▲> or decrement <▼> the volume, use the following command:
, <▼>, Double digit output port number, <▲> increment or <▼> decrement,
Ex 1: <▼> 03 <▲> <▲> <▲>
This will increment the volume by +3dB (1dB/ step).
Ex 2: <▼> 14 <▼> <▼>
This will decrement the volume by -2dB.
• To Mute, use the command:
, <▼>, Double digit output port number, the <0> key,
Ex: <▼> 03 0
This will mute output 3
• To Un-mute, use the instruction:
, <▼>, Double digit output port number, the <1> key,
Ex: <▼> 03 1
This will un-mute output 3
Memory Functions
There are 100 memory locations(0-99) available to save connection configurations. Location 0 is the power-ON default).
•
Saving Connections
To save all current connections, use the following command:
<*>, , Memory location,
Ex: <*> 5
• Restoring Connections
To restore connections from memory, use the following command:
<*>, , Memory location,
Ex: <*> 5
Note: If the current switch configuration includes assigned Scan Mode dwell time values (pg. 9), to save the current
configuration be sure to assign a memory location to it. Otherwise, when the VEEMUX-A is powered OFF, all dwell
time values will be erased. Also, saving the configuration as memory location 0 will cause it to be the power-ON default
configuration.
Menu Button
The Menu button is used to configure the RS232 port.
•
The baud rate is selected from the “Baud Rate Menu” . To access this menu, use the command:
Ex:
This will select 9600 baud
•
To set the switch address, use the following instruction:
Ex:
This will set the address at 03
Configurations that are saved into memory locations via
the keypad can be recalled via the web interface (page 23)
and vice versa.
