NTI AUDIO/HD VIDEO MATRIX SWITCH
11
Command Protocol
CPU controller commands supported by the unit are defined below. All commands must be terminated with a
return). When a command is sent, the entire string is echoed back along with a response from the addressed unit as shown in the
Command Definitions table (below). All characters in the command string are case sensitive (see Command Definitions table),
and all numbers below 10 must have a leading 0 (ex: 1 = 01).
NOTE: For units with one output or user port, use 01 for the output select.
Legend:
(All numbers must be two digits)
SW
:
Switch (01-15) MM
:
Save Into Memory Bank (00-09)
BR
:
Baud Rate Code (12,24,48,96) LL
:
Load From Memory Bank (00-09)
OP
:
Output Port (01-MAXOUTPUTS)
:
Carriage Return (Hex 0xD)
IP
:
Input Port (01-MAXINPUTS) ip
: IP address
Command Definitions
Command
String
Good Response
Description
CS SW,IP,OP
*
VIDEO Connect One Output/User Port To Input/CPU Port
CA SW,IP
*
VIDEO Connect All Output/User Ports To Input/CPU Port
RO SW,OP
*
VIDEO Read Connection For Output/User Port
AS SW,IP,OP
*
AUDIO Connect One Output/User Port To Input/CPU Port
AA SW,IP
*
AUDIO Connect All Output/User Ports To Input/CPU Port
AO SW,OP
*
AUDIO Read Connection For Output/User Port
AM SW,OP,MU
*
Set Mute State For Output/User Port
AV SW,OP,VV
*
Set Volume Level For Output/User Port
See chart on page 10 for values
AR SW,OP
*
Read Mute, Volume For Output/User Port
MU is 00 if the port is UNMUTED, MU is 01 if the port is MUTED.
VV is a value between 00 to 99 (see chart page 12)
CC SW,MM
*
Save Matrix Connections Into Memory Bank xx
Xx=00-09
RC SW,LL
*
Restore Matrix Connections From Memory Bank
CB 00,BR
None
Change baud rate of serial line, BR=12(00),24(00),48(00),96(00)
Factory default is 9,600
RS SW
*
Internal Reset
RV SW,00
*
Read NTI Version String
RU SW
*
Read Unit Size
EA SW,ip
*
Set the IP address, ip is in xxx.xxx.xxx.xxx format,
number of digits is minimum 1 and maximum 3 for each field
Leading zeroes are accepted
EM SW,ip
*
Set the Subnet mask, ip is in xxx.xxx.xxx.xxx format,
number of digits is minimum 1 and maximum 3 for each field.
Leading zeroes are accepted
EG SW,ip
*
Set the default gateway, ip is in xxx.xxx.xxx.xxx format,
number of digits is minimum 1 and maximum 3 for each field
Leading zeroes are accepted
ET SW,timeout
*
Set the website timeout; timeout = numeric string of timeout in seconds.
Values: 60, 300, 600, 900, 1800, 3600, 7200, 18000, 28800
RA SW *
Read the IP address, ip is in xxx.xxx.xxx.xxx format,
number of digits is minimum 1 and maximum 3 for each field
Leading zeroes are accepted
RM SW *
Read the Subnet mask, ip is in xxx.xxx.xxx.xxx format,
number of digits is minimum 1 and maximum 3 for each field
Leading zeroes are accepted
RG SW *
Read the default gateway, ip is in xxx.xxx.xxx.xxx format,
number of digits is minimum 1 and maximum 3 for each field
Leading zeroes are accepted
RT SW *
Read the website timeout; timeout = numeric string of timeout in
seconds.
Values: 60, 300, 600, 900, 1800, 3600, 7200, 18000, 28800
