NTI AUDIO/HD VIDEO MATRIX SWITCH
15
The following commands are now available:
Command Reply Description
H(elp) or
h(elp)
Displays the list of commands Help
CS nn,mm * Connect One Output nn To Input mm
CA nn * Connect All Outputs To Input nn
RO nn *mm
Read Connection For Output.
Returns the number of the input mm connected to output nn
CC nn *nn
Save Matrix Connections Into Memory Bank nn
nn should be between 00 and 99
RC nn *nn
Restore Matrix Connections From Memory Bank nn
nn should be between 00 and 99
CB nn *
Change baud rate of serial line, nn=12(00),24(00),48(00),96(00)
Factory default is 9600.
RV 00 *string Read NTI Version String
RU *nn,mm
Read Unit Size
Returns the number of inputs mm and the number of outputs mm
RS * Reset Unit
AS nn,mm * Connect audio input mm to output mm
AA nn * Connect audio input nn to all outputs
AO nn *nn Read audio connection for output nn
AM nn,mu *
Set mute state for output nn
mu(te State) = (00=UNMUTE, 01=MUTE)
AV nn,vv *
Set volume level for output nn
vv is a value between 00 to 99 (see chart page 12)
AR nn *MU,VV
Read mute, volume for output nn
MU is 00 if the port is UNMUTED, MU is 01 if the port is MUTED.
VV is a value between 00 to 99 (see chart page 12)
Ss nn,dwt *
Set value of Scan Mode dwell time (see page 9) for specific Output
(nn)
dwt = 000-255 (seconds) 000= disable Scan Mode
Gs nn
*
dwt Read set Scan Mode dwell time value (dwt) for specific Output (nn)
in seconds (see also "Scan Mode" on page 9)
Sa nn,mm * Set scan list of individual output nn to all inputs mm
Sc nn * Clear scan list of individual output nn
S+ nn,mm * Add input mm to Scan List of output nn
S- nn,mm * Remove input mm from Scan List of output nn
Sx nn *oooxoxxxooooxxx Display the Scan List of output nn (o=skip x=don't skip)
CP
User is prompted to introduce the
password twice
Change password- five (5) characters minimum
-
(see note 4 below) Good Bye.
Connection to host lost.
Quit telnet session
Notes:
1. The commands must be typed exactly as shown in the chart. The commands are case sensitive.
2. If a mistake is made, the user must backspace to the beginning and completely retype the command.
3. If a command is sent that the VEEMUX-A does not recognize or exceeds the configuration of the switch, the
reply "?" may be received. Check the command syntax and try again.
4. To quit the telnet session, press the keyboard keys .
