Accessories
85
To extract the MEM card from its frame:
Note: If a new MEM card is required, it is delivered in a larger frame;
use this step to remove it from the frame prior to installing it into the
handset.
1. Remove the MEM card from the frame, as shown in Figure 9.
Figure 9: Extracting the MEM card from its frame
Note: When removing the MEM card from its frame, ensure that you
do not touch the metal contacts.
To install the MEM card into the handset:
1. Place the MEM card into the MEM card tray with the notch in
position b and the metal contacts face down.
2. Shift the MEM card under the two small crescents, as shown in
Figure 10 (1).
3. Press the MEM card downwards until the small tag b locks, as shown
in Figure 10 (2).
Figure 10: Installing the MEM card into the handset
Reinstalling the battery pack
For information about reinstalling the battery pack, see “Installing the
battery pack” on page 10.
2
1
a
b
