2

W415-0210 / R / 02.27.08

Minimum Enclosure Clearances

Minimum Mantel Clearances

Nailing Tab Installation

27-28 FINISHING

Door Removal & Installation

Door Glass Replacement

L36 Louvre Installation

Log Placement

Logo Placement

29

OPTIONAL BLOWER INSTALLATION

30

OPTIONAL FAN INSTALLATION

OPTIONAL THERMOSTATIC SENSOR

31

OPERATION / MAINTENANCE

Operating

Instructions

Maintenance

30 ADJUSTMENTS

Pilot

Burner

Adjustment

Venturi

Adjustment

32-34 REPLACEMENTS

Ordering Replacement Parts

Replacement

Parts

Accessories

35-36 TROUBLE SHOOTING GUIDE
37 SERVICE

HISTORY

38 NOTES

PG 2-5 INTRODUCTION

Warranty

General Instructions

General Information

Care of Glass and Plated Parts

Specifi cations

5-16

VENTING

Venting Lengths

Vent Installations

Typical Vent Installations

Special Vent Installations

Minimum Air Terminal Location Clearances

Venting Application Flow Chart

Venting Specifi cations

Pre-Installation Preparation

17-26

INSTALLATION

Wall and Ceiling Protection

Horizontal Installation

Vertical Installation

Using Flexible Vent Components

Fireplace Vent Connection

Using Rigid Vent Components

Vertical Venting Installation

Restricting Vertical Vents

Mobile Home Installation

Gas Installation

Optional Wall Switch Installation

Framing

NOTE: CHANGES, OTHER THAN EDITORIAL, ARE DENOTED BY A VERTICAL LINE IN THE MARGIN.

• Do not burn wood or other materials in this fi replace.
• Adults and especially children should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or
clothing ignition. Supervise young children when they are in the same room as the fi replace.
• Clothing or other fl ammable material should not be placed on or near the fi replace.
• Due to high temperatures, the fi replace should be located out of traffi c and away from furniture and draperies.
• Ensure you have incorporated adequate safety measure to protect infants/toddlers from touching hot surfaces.
• Even after the fi replace is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from hot surfaces. These screens
and guards must be fastened to the fl oor.
• Any safety screen or guard removed for servicing must be replaced prior to operating the fi replace.
• It is imperative that the control compartments, burners and circulating blower and its passageway in the fi replace and venting system
are kept clean. The fi replace and its venting system should be inspected before use and at least annually by a qualifi ed service person.
More frequent cleaning may be required due to excessive lint from carpeting, bedding material, etc. The fi replace area must be kept clear
and free from combustible materials, gasoline and other fl ammable vapours and liquids.
• Under no circumstances should this fi replace be modifi ed.
• This fi replace must not be connected to a chimney fl ue pipe serving a separate solid fuel burning appliance.
• Do not use this fi replace if any part has been under water. Immediately call a qualifi ed service technician to inspect the fi replace and to
replace any part of the control system and any gas control which has been under water.
• Do not operate the fi replace with the glass door removed, cracked or broken. Replacement of the glass should be done by a licensed
or qualifi ed service person.
• Do not strike or slam shut the fi replace glass door.
• This fi replace uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple supplied by Wolf Steel Ltd.
• Pressure relief doors must be kept closed while the fi replace is operating to prevent exhaust fumes containing carbon monoxide, from
entering into the home. Temperatures of the exhaust escaping through these openings can also cause the surrounding combustible
materials to overheat and catch fi re.
• Only doors / optional fronts certifi ed with the unit are to be installed on the appliance.

TABLE OF CONTENTS

RETAIN THIS MANUAL FOR FUTURE REFERENCE

!
