7

Table 2

describes the 400-4TX and 8100-4TX MDA front-panel.

Table 2

400-4TX and 8100-4TX MDA front panel

Item

Label

Description

1

100

100BASE-TX port status LEDs (green):

On: The corresponding port is set to operate at
100 Mb/s.

Off: The link connection is bad or there is no
connection to this port.

Blinking: The corresponding port is management
disabled.

2

10

10BASE-T port status LEDs (green):

On: The corresponding port is set to operate at
10 Mb/s.

Off: The link connection is bad or there is no
connection to this port.

Blinking: The corresponding port is management
disabled.

3

F Dx

Full-duplex port status LEDs (green):

On: The corresponding port is in full-duplex mode.

Off: The corresponding port is in half-duplex
mode.

4

Activity

Port activity LEDs (green):

Blinking: Indicates the network activity level for the
corresponding port. A high level of network activity
can cause LEDs to appear to be on continuously.

5

10BASE-T/100BASE-TX RJ-45 (8-pin modular) port
connectors.
