5-12 Disassembly and Reassembly
Illustrated Parts Breakdown
This section contains the NEC CSD part descriptions and the illustrated parts
breakdown (IPB) figure for the Direction SP B-Series desktop and minitower
computers.
The following table and IPB lists and illustrates the field-replaceable parts for
the desktop computer. The minitower table and IPB follow the desktop IPB.
Direction SP B-Series Desktop Field-Replaceable Parts List
*
Item Description
1 Keyboard, Ergo
2a 32X CD-ROM drive
2b 40X CD-ROM drive
3 Seagate Travan tape drive, backup
4 Iomega ATAPI Zip drive
5a 6.4-GB hard drive, IDE UDMA
5b 10.2-GB hard drive, IDE UDMA
5c 14.4-GB hard drive, IDE UDMA
6 Microphone
7 3.5-inch diskette drive
8 Speaker, internal
9 Left side cover
10 Top cover (access cover)
11 Front panel
12 Right side cover
13 Power supply - Sparkle
14a Altec Lansing speakers, ACS90
14b Altec Lansing speakers, ACS45
15a 8-MB Video board, Diamond Stealth II G460, AGP
15b 8-MB Video board, ATI XPERT98, AGP
15c 16-MB Video board, Diamond Viper V550, AGP
16a 56-Kbps modem board
16b 56 Kbps PCI Winmodem
16c 56 Kbps Diamond Supra V.90 PCI modem
_______
* This data was prepared April 1999. For an up-to-date listing of spare parts, please call FaxFlash SM at
1-888-329-0088 (or 1-916-379-4780 outside the U.S.) and order document 42102343.
