Connector Pin Assignments B-11
DIMM Socket Pin Assignments
Pin
Description
Pin
Description
Pin
Description
Pin
Description
31
NC
73
V
DD
115
RAS
157
V
DD
32
V
SS
74
DQ28
116
V
SS
158
DQ60
33
A0
75
DQ29
117
A1
159
DQ61
34
A2
76
DQ30
118
A3
160
DQ62
35
A4
77
DQ31
119
A5
161
DQ63
36
A6
78
V
SS
120
A7
162
V
SS
37
A8
79
CK2
121
A9
163
CK3
38
A10
80
NC
122
BA0
164
NC
39
NC (BA1)
81
NC
123
NC (A11)
165
SA0
40
V
DD
82
SDA
124
V
DD
166
SA1
41
V
DD
83
SCL
125
CK1
167
SA2
42
CK0
84
V
DD
126
NC (A12)
168
V
DD
AGP Connector
The following table provides the pin assignments for the AGP connector.
AGP Connector Pin Assignments
Pin
Description
Pin
Description
Pin
Description
Pin
Description
A1
+12V
B1
No connect
A34
Vcc3.3
B34
Vcc3.3
A2
No connect
B2
Vcc
A35
AD22
B35
AD21
A3
Reserved
B3
Vcc
A36
AD20
B36
AD19
A4
No connect
B4
No connect
A37
Ground
B37
Ground
A5
Ground
B5
Ground
A38
AD18
B38
AD17
A6
INTA#
B6
INTB#
A39
AD19
B39
C/BE2#
A7
RST#
B7
CLK
A40
Vcc3.3
B40
Vcc3.3
A8
GNT1#
B8
REQ#
A41
FRAME#
B41
IRDY#
A9
Vcc3.3
B9
Vcc3.3
A42
Reserved
B42
+3.3V aux
A10
ST1
B10
ST0
A43
Ground
B43
Ground
A11
Reserved
B11
ST2
A44
Reserved
B44
Reserved
A12
PIPE#
B12
RBF#
A45
Vcc3.3
B45
Vcc3.3
A13
Ground
B13
Ground
A46
TRDY#
B46
DEVSEL#
A14
No connect
B14
No connect
A47
STOP#
B47
Vcc3.3
A15
SBA1
B15
SBA0
A48
PME#
B48
PERR#
