Page 34
Appendix B
Connecting I/O Signals
B-2
ni.com
Figure B-1. NI 781xR Connector Locations
1
Connector Overlay for the
NI PXI-781x
2
Connector Overlay for the
NI PCI-781x
CONNECT
OR 0 (DIO)
CONNECT
OR 1 (DIO)
CONNECT
OR 2 (DIO)
CONNECT
OR 3 (DIO)
CONNECT
OR 3 (DIO)
CONNECT
OR 2 (DIO)
CONNECT
OR 0 (DIO)
CONNECT
OR 1 (DIO)
PCI-781xR
1
2
