Dimensions – National Instruments NI sbRIO-960x User Manual
Page 3
© National Instruments Corporation
3
NI sbRIO-960x
Dimensions
This section contains dimensional drawings of the sbRIO devices. For
three-dimensional models, go to
ni.com/singleboard
and look on the
Resource tab for the sbRIO device you are using.
Note
The plated mounting holes are all connected to P1, the ground lug. Connect P1 or
one of the plated mounting holes securely to earth ground.
