USER GUIDE
NI sbRIO-960x
Single-Board RIO OEM Devices
This document provides dimensions, pinouts, connectivity information,
and specifications for the National Instruments sbRIO-9601 and
sbRIO-9602. The devices are referred to inclusively in this document as
the sbRIO-960x.
Caution
National Instruments makes no product safety, electromagnetic compatibility
(EMC), or CE marking compliance claims for the sbRIO-960x. The end-product supplier
is responsible for conformity to any and all compliance requirements.
Caution
Exercise caution when placing the sbRIO-960x inside an enclosure. Auxiliary
cooling may be necessary to keep the device under the maximum ambient temperature
rating of 55 °C.
The following figure shows the sbRIO-960x.
Figure 1. sbRIO-960x
Document Outline
- NI sbRIO-960x User Guide
- What You Need to Get Started
- Dimensions
- I/O and Other Connectors on the sbRIO Device
- Figure 4. sbRIO-960x Parts Locator Diagram
- Table 1. sbRIO Connector Descriptions
- Figure 5. Pinout of I/O Connector P2, 3.3 V Digital I/O
- Figure 6. Pinout of I/O Connector P3, 3.3 V Digital I/O
- Figure 7. Pinout of I/O Connector P4, 3.3 V Digital I/O
- Figure 8. Pinout of I/O Connector P5, 3.3 V Digital I/O
- Figure 9. J1, RS-232 Serial Port
- Table 2. RS-232 Serial Port Pin Descriptions
- Connecting the sbRIO Device to a Network
- Powering the sbRIO Device
- Connecting Serial Devices to the sbRIO Device
- Using the Internal Real-Time Clock
- Configuring DIP Switches
- Using the Reset Button
- Understanding LED Indications
- Resetting the Network Configuration of the sbRIO Device
- Integrated 3.3 V Digital I/O
- Specifications
- Where to Go for Support
