CHAPTER 3 CPU ARCHITECTURE
User’s Manual U12978EJ3V0UD
45
Table 3-2. Special Function Register List (1/3)
Address Special Function Register (SFR) Name Symbol R/W Manipulatable Bit Unit After Reset
1 Bit 8 Bits 16 Bits
FF00H Port 0 P0 R/W √ √ — 00H
FF01H Port 1 P1 √ √ —
FF02H Port 2 P2 √ √ —
FF04H Port 4 P4 √ √ —
FF07H Receive data PID USBRD R — √ —
FF08H Receive data address 0 USBR0 USBR10 — √ √ Undefined
FF09H Receive data address 1 USBR1 — √
FF0AH Receive data address 2 USBR2 USBR32 — √ √
FF0BH Receive data address 3 USBR3 — √
FF0CH Receive data address 4 USBR4 USBR54 — √ √
FF0DH Receive data address 5 USBR5 — √
FF0EH Receive data address 6 USBR6 USBR76 — √ √
FF0FH Receive data address 7 USBR7 — √
FF10H Transmit/receive shift register 10 SIO10 R/W — √ —
FF14H Handshake packet transmit reservation
register
HTX
RSV
USB
CON
√ √ √ 00H
FF15H Data packet transmit reservation register DTX
RSV
√ √
FF20H Port mode register 0 PM0 √ √ — FFH
FF21H Port mode register 1 PM1 √ √ —
FF22H Port mode register 2 PM2 √ √ —
FF24H Port mode register 4 PM4 √ √ —
FF30H Port output mode register 0 POM0 √ √ — 00H
FF31H Port output mode register 1 POM1 √ √ —
FF42H Timer clock select register 2 TCL2 — √ —
FF50H 8-bit compare register 00 CR00 W — √ — Undefined
FF51H 8-bit timer counter 00 TM00 R — √ — 00H
FF53H 8-bit timer mode control register 00 TMC00 R/W √ √ —
FF54H 8-bit compare register 01 CR01 W — √ — Undefined
FF55H 8-bit timer counter 01 TM01 R — √ — 00H
FF57H 8-bit timer mode control register 01 TMC01 R/W √ √ —
FF60H Token PID compare register TIDCMP W — √ —
FF61H Token address compare register ADRCMP — √ —
Note 16-bit access is possible only in short direct addressing.
