Configuring Ethernet PCI Adapters
2-22 Express5800/320Ma: PCI Adapter Guide
Configuring Virtual LANs Over a Team
C A U T I O N !
Configuring a VLAN over an Ethernet team disrupts the
network traffic over the team.
N O T E
Configuring VLANs is optional. You can have an Ethernet
team without VLANs.
1. Start the PROSet utility if you have not already done so (see “Starting PROSet” on
page 2-7 ).
2. In the left pane of the Intel(R) PROSet for Wired Connections dialog box,
right-click the appropriate team. In the menu that appears, click Add VLAN (see
Figure 2-11 ).
Figure 2-10. Adding a VLAN to a Team
3. In the Add New VLAN dialog box ( Figure 2-11 ), enter the VLAN ID. The VLAN ID
must match the VLAN ID configured on the switch.
