Routing Counter n Internal Output to an Output
Terminal
You can route Counter n Internal Output to any output PFI <6..9> or
RTSI <0..7> terminal. All output PFIs are set to high-impedance at startup.
Frequency Output Signal
The Frequency Output (FREQ OUT) signal is the output of the frequency
output generator.
Routing Frequency Output to a Terminal
You can route Frequency Output to any output PFI <6..9> terminal. All
PFIs are set to high-impedance at startup.
Default Counter Terminals
By default, NI-DAQmx routes the counter/timer inputs and outputs to the
PFI pins, shown in Table 7-4.
Table 7-4. NI 6232/6233 Device Default NI-DAQmx Counter/Timer Pins
Counter/Timer Signal
Default Pin Number (Name)
Port
CTR 0 SRC
13 (PFI 0)
P0.0
CTR 0 GATE
32 (PFI 1)
P0.1
CTR 0 AUX
33 (PFI 2)
P0.2
CTR 0 OUT
17 (PFI 6)
P1.0
CTR 0 A
13 (PFI 0)
P0.0
CTR 0 Z
32 (PFI 1)
P0.1
CTR 0 B
33 (PFI 2)
P0.2
CTR 1 SRC
15 (PFI 3)
P0.3
CTR 1 GATE
34 (PFI 4)
P0.4
CTR 1 AUX
16 (PFI 5)
P0.5
CTR 1 OUT
36 (PFI 7)
P1.1
CTR 1 A
15 (PFI 3)
P0.3
CTR 1 Z
34 (PFI 4)
P0.4
CTR 1 B
16 (PFI 5)
P0.5
