1
2. Cable Connection and Screen Adjustment
-. Screen Adjustment (Analog Input)
Screen adjustments for the LCD monitor should be used in suppressing screen flickering
and also for adjusting the screen to its proper position. There is only one correct position
for each display mode. It is also recommended to use the ScreenManager function when
first installing the display or whenever changing the system. For convenience, an easy
set-up Program installed on the utility disk to assist in the set-up procedure is provided.
NOTE
•Allow the LCD monitor to stabilize for at least 30 minutes before making image
adjustments.
Adjustment Procedure
About how to use the ScreenManager, refer to p. 21.
1
. Adjust by using in the ScreenManager
menu.
Select in the ScreenManager menu
and select “Execute”.
The Auto Adjustment function begins (showing a running status message) to
adjust clock, phase, display position, and resolution automatically.
NOTE
•The Auto Adjustment function is intended for use on the Macintosh and on AT-
compatible PC running Windows. It may not work properly in either of the
following cases.
When running an AT-compatible PC on MS-DOS (Not windows). The
background color for the “wall paper” or “desktop” pattern is set to black.
• It cannot work correctly using with some graphics cards.
If the appropriate screen cannot be made by using Menu, adjust
the screen through the following procedures. If the appropriate screen can be made,
proceed to step 3.
2
. Adjust the advanced setting by using menu in the
ScreenManager.
(1) Vertical bars appear on the screen.
Use the (p. 44) adjustment.
Select the and eliminate the vertical bars by using the Right and Left
of the Control Switchs. Do not continuously press the Control Switchs, as the
adjustment value will change quickly and make it difficult to locate the most
suitable adjustment point.
