© National Instruments Corporation
3-1
DAQArb 5411 User Manual
Chapter
3
Signal Connections
This chapter describes the I/O connectors, signal connections, and
digital interface to the DAQArb 5411.
I/O Connector
The DAQArb 5411 has four connectors: three SMB connectors and a
50-pin mini-SCSI type connector, as shown in Figure 3-1.
Figure 3-1. DAQArb 5411 I/O Connector
ARB
SYNC
PLL Ref
Dig Out
