IP Phone handset status indicators, icons, and softkeys 25
Table 3
IP Phone handset status indicators, icons, and softkeys (cont’d.)
Indicator light or Icon Description and Function
Envelope Indicates a new voicemail message is waiting or a missed call in the
Inbox. An on-screen message tells you whether you missed a call or
have a message waiting. Located on the status line.
Line The Line Indicator area displays the line currently in use. Any lines
which are not idle or active (for example, if the line is on hold or
forwarded) have a plus sign (+) in front of the entry for that line.
Located on the status line.
Hold Indicates that a call is on hold.
Locked Indicates the keypad is locked.
Message Indicates an incoming call from a Messaging application.
Mute Indicates that the microphone is not transmitting sound. The muted
indicator softkey must be pressed to activate this function. Press the
Mute softkey again to unmute the microphone.
No Service Indicates that you are out of the service coverage area and cannot
receive or place calls. The out-of-service tone plays. Return to the
coverage area to reestablish a connection.
Push-to-talk (PTT) and
Priority PTT Indicates an incoming PTT call, on the WLAN Handset 2211, 2212,
and 6140.
The priority PTT ring icon indicates an incoming call on the priority
PTT channel. This call overrides all other calls.
Signal Strength Gives a visual indication (from weak to strong) of the signal strength
to the handset. A series of symbols is used.
Speakerphone Indicates when the speakerphone is active, on the WLAN Handset
6100 Series.
Telephone Indicates a regular incoming telephone call.
Softkey label Description and Action
Back Go Back
Returns to the previous menu display.
Bkspc Backspace
Clears the selected entry to the left of the curser without clearing all
the characters. Appears when you create a Label.
CAPS or caps Change case
Toggles to allow a change in case when you enter alphabetical text.
Cfg Configure
Opens the Config menu.
Clr Clear
Deletes the entry.
Carrier VoIP
