Advanced functions
70
Figure 25: Call icons
For group call icon explanations, see "Group call icons" on page 70 .
Figure 26: Group call icons
For system notification icon explanations, see "System notification icons"
on page 70 .
Figure 27: System notification icons
2. To view the details concerning an individual entry, select the entry,
and select Log Details from the menu.
The Details screen appears. See “Logs details screen” on page 71 .
