NetGear Print Server Manual

Printer Type

These are text fields, used to describe the printer driver used for each port. Currently the only printer
driver supported for AppleTalk is LaserWriter.

Communication
Protocol

Sets whether the port uses ASCII or Binary Communication Protocol. Binary communication is faster
than ASCII, but ASCII communication is more reliable. The default is ASCII.

Logical Port Tab

Logical printers (Logical Ports) can be used under Linux or Unix. The Print Server supports 3 Logical
Ports. This screen allows configuration of Logical Ports.

Logical Port Tab Window

Logical Port Tab Fields

Field Description

Current
Selected
Logical Port

Selects the logical port to be configured. Eight logical ports are available for print servers with two printer
ports; three logical ports are available for one printer port print servers.
