NetGear Print Server Manual
Wireless Link Info
When click on Link Info button in Figure 3-5, the Wireless Link Info screen shows. See Figure
3-6 for the current wireless link information.
Figure 3-6 Wireless Link Information Screen
Wireless Link Info Fields
Stat: Associated
– BSS ID
The other wireless party which PS111W wireless communication is associated with
Current Channel
The current used wireless channel.
For Network type as infrastructure mode, the channel is automatically selected the same as with the
Access Point.
Current Tx Rate The current wireless communication speed
Throughput
Tx: The current transmitting rate in the unit of byte per second
Rx: The current receiving rate in the unit of byte per second
Link Quality: The quality of the link, which is excellent or poor
Signal Strength: The signal amplification, which is excellent or poor
Note: The information is only meaningful while there is a NETGEAR MA401 802.11b wireless PC
card in the PS111W slot.
17
