May 2003 Installing the server and connecting the peripheral devices
Part 2: 702t Server Hardware Installation 41
To set the modem DIP switches
Use a pair of tweezers or a small screw driver to set the DIP switches as
described in the “Change to” column of the following table:
Note: ON is down. OFF is up.
DIP
switch Default
setting Change
to
Function
1 OFF OFF Data Terminal Ready (DTR) override
„ OFF: Normal DTR operations. (The
computer must provide a DTR signal for the
modem to accept commands. If DTR is
dropped, the call is terminated.)
„ ON: The modem ignores DTR (override).
2 OFF OFF Verbal/numeric result codes
„ OFF: Verbal (word) results.
„ ON: Numeric results.
3 ON ON Result code display
„ OFF: Suppresses result codes.
„ ON: Enables result codes.
4 OFF OFF Command mode local echo suppression
„ OFF: Displays keyboard commands.
„ ON: Suppresses echo.
5 ON ON Auto answer suppression
„ OFF: The modem answers on the first ring,
or higher if specified in NVRAM.
„ ON: Disables auto answer.
