Features
• Large diaphragm cardioid
microphone
• Pressure-gradient transducer
with one-diaphragm capsule
• Transformerless circuitry
• Extremely low noise: 7 dB-A
• Includes swivel mount
• Straightforward handling
for homerecording and
professional studios
• High-quality professional
equipment for limited budgets
he TLM 103 is the ideal large diaphragm microphone
for all professional and semi-professional applications
requiring the utmost in sound quality on a limited budget.
By utilizing the tried and true transformerless circuit found
in numerous Neumann microphones, the TLM 103 features
yet unattained low self-noise and the highest sound pres-
sure level transmission. The capsule, derived from that used
in the U 87, has a cardioid pattern, is acoustically well-
balanced and provides extraordinary attenuation of signals
from the rear.
The TLM 103 is available in satin nickel and matte black.
Delivery includes an SG 1 metal swivel mount and a wooden
jeweler’s box.
Applications
Due to the universal cardioid pattern, straightforward han-
dling, extremely low self-noise level, and finally, the price,
the TLM 103 is predestined for all demanding applications
from home recording to professional broadcasting and
commercial recording studios.
Polar pattern
The TLM 103 is equipped with a large diaphragm capsule
with cardioid pattern. By focusing on this pattern – used in
most recording situations – the attenuation of unwanted rear
sound has been optimized.
Off-axis sounds are rendered naturally while isolation is
increased. This also leads to a high feedback suppression
when the microphone is used in live situations or where loud-
speaker playback is a factor.
Acoustic features
The TLM 103 is addressed from the front, marked with the
red Neumann logo on the microphone body.
The K 103 large diaphragm capsule is based on the K 87,
well known from the U 67 / U 87 microphones.
Application Hints
• A universal cardioid mic
• Vocalist recording
• Announcer’s mic for broadcasting/voice over
• Due to minimal self-noise: on-air mic for radio/broadcast,
very low amplitude signals, radio drama, sampling,
foley/sound effects
• Home recording and project studios
• Spot mic for wind instruments, strings, percussion,
guitar amps, drum overhead
These are just some of the most common applications. We
recommend additional experimentation to gain maximum use
from this microphone.
Delivery Range
TLM 103 (mt) Microphone, SG 1 Stand mount swivel in
Wooden box
Mono Mono Mono Mono Mono set: set: set: set: set: TLM 103 (mt) Microphone, EA 1 (mt) Elastic
suspension in aluminium case
Stereo Stereo Stereo Stereo Stereo set: set: set: set: set: 2x TLM 103 (mt) Microphone, 2x EA 1 (mt)
Elastic suspension in aluminium case
Studio Studio Studio Studio Studio set: set: set: set: set: TLM 103 (mt) Microphone, EA 1 (mt) Elastic
suspension
Catalog No.
TLM 103 ................................................................................ ni ............... 008430
TLM 103 mt ........................................................................ blk ............ 008431
TLM 103 Mono set ........................................................ ni ............... 008508
TLM 103 mt Mono set ................................................ blk ............ 008509
TLM 103 Stereo set ....................................................... ni ............... 008501
TLM 103 mt Stereo set ............................................... blk ............ 008502
TLM 103 Studio set ........................................................ ni ............... 008545
TLM 103 mt Studio set ................................................ blk ............ 008544
Selection of Accessories
Power supply, N 248 (EU) ....................................... blk ............ 008537
Power supply, N 248 (US) ........................................ blk ............ 008538
Power supply, N 248 (UK) ....................................... blk ............ 008539
Auditorium hanger, MNV 87 .................................... ni ............... 006804
Auditorium hanger, MNV 87 mt ............................ blk ............ 006806
Elastic suspension, EA 1 .............................................. ni ............... 008449
Elastic suspension, EA 1 mt ...................................... blk ............ 008450
Popscreen, PS 15 .............................................................. blk ............ 008472
Popscreen, PS 20 a ......................................................... blk ............ 008488
Microphone cable, IC 3 mt ......................................... blk ............ 006543
Microphone cable, IC 4 ................................................. ni ............... 006547
A complete survey and detailed descriptions of all accessories
are contained in the accessories catalog.
Meaning of color codes: blk = black, ni = nickel
