138
Stand Mounts and Miscellaneous Mechanical Adapters
Stereo Mount STH 100
Stereo mount with a swivel mount and
two holders, for two detached miniature
microphone capsules. Two stereo re-
cording methods are then possible.
One holder enables the microphone set-
up according to the “ORTF Method”:
Two detached capsules are snapped into
the clamps at the end of the holder. The
distance between diaphragms is then
170 mm, with an angle of 110°.
The other pair of holders allows stereo
setups according to the “Coincidence
Method”: Capsules are installed acousti-
cally at one point in space, however,
freely adjustable to any angle between
30° and 180°.
The swivel mount has a 5/8"-27 thread,
plus a thread adapter to connect to
1/2"- and 3/8" stands.
STH 100 ............... blk ........ Cat. No. 007315
Swivel Joint SG-AK
The SG-AK swivel mount can be inserted
between active capsules and the output
stage of the KM 100 system. The capsule
can then be swiveled and orientated
through 90°. In combination with an
elastic suspension and a table flange, a
mechanically decoupled, unobtrusive
setup can be realised, e.g. for TV news
announcers. Length 45 mm, Ø 22 mm.
SG-AK ................... blk ........ Cat. No. 008452
Stereo Mount STH 120
The STH 120 stereo mount accepts two
detached miniature microphone cap-
sules, parallel and one above the other
for MS stereo recordings. It is rotatable
and swivelable. The swivel mount has a
5/8"-27 thread, plus a thread adapter to
connect to 1/2"- and 3/8" stands.
STH 120 ............... blk ........ Cat. No. 008422
