19
Technical Data
General Specifications of the Solution-D microphones General Specifications of the Solution-D microphones General Specifications of the Solution-D microphones General Specifications of the Solution-D microphones General Specifications of the Solution-D microphones
Interface: AES 42
Remote controlled functions:
- Polar pattern
4)
- Low-cut: flat, 40, 80, 160 Hz
- Pre-attenuation: 0 , –6, –12, –18 dB
- Gain: 0...63 dB in 1 dB steps, clickless
- Testsignal: 1 kHz, pink noise, white noise
- Sampling rates: 44.1, 48, 88.2, 96, 176.4, 192 kHz
- Parametric compressor/limiter (incl. de-esser function)
- Independent peak limiter avoiding any clipping
- Switch functions: soft muting, phase reverse, signal lights
- Signal lights: red
4) and blue LEDs
- System functions, firmware download
A/D conversion: Neumann process (patented),
28-bit internal word length
Digital signal processing: Fixed-point,
variable internal word length 28 bits to 60 bits
Synchronization:
- Asynchronous operation (free-running, AES 42 - Mode 1),
basic frequency accuracy: ± 25 ppm
- Synchronous operation (AES 42 - Mode 2),
pulling range: Min. ± 100 ppm
Power supply (phantom power complying with AES 42)
Output: XLR3M, 24 bits as per AES/EBU (AES 3)
D-01 Specifications D-01 Specifications D-01 Specifications D-01 Specifications D-01 Specifications
Acoustic transducer: K 07 large double-diaphragm capsule,
diameter 30 mm with protected internal electrodes
Directional characteristic: 15 remote controllable polar patterns,
from omni to cardioid to figure-8
Frequency response: 20 Hz to 20 kHz
Free-field sensitivity
1)2) : –44 dBFS
Equivalent noise level, CCIR 3) : 19 dB
Equivalent noise level, A-weighted 3) : 8 dB-A
Signal-to-noise ratio 2) , CCIR 3) : 75 dB
Signal-to-noise ratio 2) , A-weighted 3) : 86 dB
Maximum SPL at 0 dBFS: 138 dBSPL
Dynamic range, A-weighted
3) : 130 dB
Supply voltage range: +6 V to +10,5 V
Current consumption: max. 220 mA
Weight: approx. 700 g, Diameter: 63.5 mm, Length: 185 mm
KM D + KK 183 / 184 / 185 Specifications KM D + KK 183 / 184 / 185 Specifications KM D + KK 183 / 184 / 185 Specifications KM D + KK 183 / 184 / 185 Specifications KM D + KK 183 / 184 / 185 Specifications
Acoustic transducer: KK 183/184/185 (known from Series 180)
Directional characteristic: Omni/cardioid/hypercardioid
Frequency response: 20 Hz to 20 kHz
Free-field sensitivity
1)2) : –41/–39/–42 dBFS
Equivalent noise level, CCIR 3) : 25/22/25 dB
Equivalent noise level, A-weighted 3) : 13/13/16 dB-A
Signal-to-noise ratio 2) , CCIR 3) : 69/70/69 dB
Signal-to-noise ratio 2) , A-weighted 3) : 81/81/78 dB
Maximum SPL at 0 dBFS: 135/133/136 dBSPL
Preset:
- Sampling rates: 44.1, 48 or 96 kHz
- Gain: 10 dB (variable with DMI-2)
- Compressor on, Attack time 100 ms, Release time 0.5 s,
Threshold –10 dBFS, Ratio 2:1
Supply voltage range: +7 V to +10,5 V
Current consumption: max. 150 mA
Weight: approx. 80/84/88 g, Diameter: 22 mm, Length: 108 mm
KM D + KK 131 / 143 / 145 Specifications KM D + KK 131 / 143 / 145 Specifications KM D + KK 131 / 143 / 145 Specifications KM D + KK 131 / 143 / 145 Specifications KM D + KK 131 / 143 / 145 Specifications
Acoustic transducer: KK 131/143/145
Directional characteristic: Omni free field equalized/cardioid wide
angle/ cardioid low frequency roll-off
Frequency response: 20 Hz to 20 kHz
Free-field sensitivity
1)2) : –41/–39/–40 dBFS
Equivalent noise level, CCIR 3) : 24/24/24 dB
Equivalent noise level, A-weighted 3) : 13/13/14 dB-A
Signal-to-noise ratio 2) , CCIR 3) : 70/70/70 dB
Signal-to-noise ratio 2) , A-weighted 3) : 81/81/80 dB
Maximum SPL at 0 dBFS: 135/133/134 dBSPL
Preset:
- Sampling rates: 44.1, 48 or 96 kHz
- Gain: 10 dB (variable with DMI-2)
- Compressor on, Attack time 100 ms, Release time 0.5 s,
Threshold –10 dBFS, Ratio 2:1
Supply voltage range: +7 V to +10,5 V
Current consumption: max. 150 mA
Weight: approx. 80/84/88 g, Diameter: 22 mm, Length: 108 mm
TLM 103 D Specifications TLM 103 D Specifications TLM 103 D Specifications TLM 103 D Specifications TLM 103 D Specifications
Acoustic transducer: Pressure gradient transducer
Directional characteristic: Cardioid
Frequency response: 20 Hz to 20 kHz
Free-field sensitivity
1) : –39 dBFS
Equivalent noise level, CCIR 3) : 17.5 dB
Equivalent noise level, A-weighted 3) : 7 dB-A
Signal-to-noise ratio 2) , CCIR 3) : 76.5 dB
Signal-to-noise ratio 2) , A-weighted 3) : 87 dB
Maximum SPL at 0 dBFS: 134 dBSPL
Dynamic range, A-weighted
3) : 127 dB
Preset:
- Sampling rates: 44.1, 48 or 96 kHz
- Gain: 10 dB (variable with DMI-2)
- Compressor on, Attack time 100 ms, Release time 0.5 s,
Threshold –10 dBFS, Ratio 2:1
Supply voltage range: +6 V to +10,5 V
Current consumption: max. 150 mA
Weight: approx. 460 g, Diameter: 60 mm, Length: 132 mm
DMI-2 (Digital Microphone Interface) Specifications DMI-2 (Digital Microphone Interface) Specifications DMI-2 (Digital Microphone Interface) Specifications DMI-2 (Digital Microphone Interface) Specifications DMI-2 (Digital Microphone Interface) Specifications
2 channels, Inputs: XLR3F, AES 42
Outputs: XLR3M, AES/EBU, 24 bit
Control bus: RS 485 via RJ 45 jack. Second RJ 45 jack for
cascading purposes (up to 4 DMI devices today, 16 devices in
future). Connection to the computer‘s USB port via Neumann
USB 485 interface converter (included).
User Port: 9-pin sub-D, 3 functions per channel
Synchronization: AES 42 - Mode 2 (PLL system using an external
Word Clock and remote controlling the VCXO in the microphone,
default mode), AES 42 - Mode 1, (asynchronous, needs a sample
rate converter (SRC) at the receiver side).
