Reference Manual for the RangeMax 240 Wireless Router WPNT834
6-4 Maintenance
v1.0, November 2005
Click the Show Statistics button to display router usage statistics, as shown below.
This screen shows the following statistics:
Default Gateway The WAN (Internet) default gateway the router communicates with.
DNS Server The IP address of the DNS server which provides network name to IP address
translation.
Figure 6-3
Table 6-3: Router Statistics Items
Item Description
System Up Time The amount of time since the router was last restarted.
Port The statistics for the WAN (Internet) and LAN (local) ports. For each port, the screen
displays:
Status The link status of the port.
TxPkts The number of packets transmitted on this port since reset or manual clear.
RxPkts The number of packets received on this port since reset or manual clear.
Collisions The number of collisions on this port since reset or manual clear.
Tx B/s The current transmission (outbound) bandwidth used on the WAN and LAN ports.
Rx B/s The current reception (inbound) bandwidth used on the WAN and LAN ports.
Up Time The time elapsed since this port acquired the link.
Poll Interval Specifies the intervals at which the statistics are updated in this window.
Set Interval Enter a time and click the Set Interval button to set the polling frequency.
Table 6-2: Connection Status Items (continued)
Item Description
