DECT Industrial Handset User Guide

Issue 02

Galway M1 Design Support

5

2

GENERAL

2.1 Handset


The handset has 22 keys which are described as follows:

Voice (short press) & E2 (long press) Message function.

In Menu - Cursor left
After a digit - delete last digit.
Long press - delete all.
In on hook - Redial menu.

In Menu - Cursor right.

Confirmation or jump to next level in the menu.
In off hook - Mute.
Long key press turns the handset OFF.

In off hook - Recall.
In on hook - Enter or exit the menu structure.

On hook/off hook and turn ON handset.

” * ”

Used with

to enable keypad lock. Long press for a pause.


“0-9”

Digits or letters in alphanumeric mode


“ # “

Choose uppercase or lowercase letters in alphanumeric mode.

Telephone

book


Blue top key SOS button.


The two keys at the right hand side of the handset are for volume control.
