Panasonic BT-LH2600W - Manual (Page 9)

9
Video monitor unit
AC Adaptor
10-M4,L=10mm Max
46 (1.8)
215 (8.5)
60 (2.4)
100 (3.9)
200 (7.9)
169 (6.7)
100 (3.9)
100 (3.
9)
116.5 (4.6)
220 (8.7) 1
9
6 (7.7)
12 (0.5)
18 (0.7)
370 (14.6)
346 (13.6)
440 (17.3)
30 (1.2)
410 (16.1)
599 (23.6)
343.8 (13.5)
550.08 (21.7)
• When installing the monitor in one place permanently, we
recommend that you fix the monitor in place using the
screw holes in the lower part of the stand.
Unit: mm (inches)
46 (1.8) 64 (2.5) 73.5 (2.9) 48.5 (1.9)
150 (5.9)
200 (7.9)
232 (9.1) 4.5 (0.2)
46 (1.8)
177 (7.0)
Unit: mm (inches)
• The rating plate is on the underside of the AC Adapter.
Dimensions
